Description
Salt electrolysis DELUXE PLUS +
- Automatic treatment for optimum maintenance.
- Remote control via the Bluezone app.
- Intuitive and user-friendly interface.
- High quality self-cleaning cell.
- 2 production modes (depending on the model): NS (normal production) and LS (low salt).
DELUXE PLUS + advantages:
Smart Power’ technology: constant chlorine production under all circumstances, a technology that extends the life of the cell.
– Production mode: works at any salt level – (NS): from 2.5 g/l and (LS): 1.5 g/l, no high limit).
– Remote control via Bluetooth: remote control and update with the Bluezone app.
– Superboost mode: super chlorination for up to 48 hours to meet a high need for disinfectant.
– Cover function (low): when the automatic cover is closed or the
When the automatic cover is closed or the bubble cover is in place, it automatically reduces chlorine production to prevent damage caused by excessive amounts of chlorine in the water.
– Self-diagnosis function: electrolysis test to check the condition of the components.
– Automatic winterization function: automatic winterization and restart from 15°C.
– Alerts: Low water, low salt, cell failure.
Specific DELUXE PLUS + features:
Superboost function: 12h or 24h – 48h setting, with memory.
– Low function: Dry contact, divides chlorine production by 5.
– Polarity reversal time: Adjustable from 2h to 24h in 1h increments.
Includes:
Control box, cell, connection cable between cell and control box (2 m), water/salt/low temperature sensor, transparent accessory holder, salt and water hardness analysis kit, power cable (2 m), 63 mm (x2) load socket (50 mm < 80m3), 63 x 50 mm (x2) reducer, wall bracket (with screws) and instruction manual.
Warning
Alarm signals indicating low water, low salt, cell failure.
Smart Power” technology
– Constant chlorine production under any circumstances.
– Technology that extends the life of the cell.
Backlit LCD screen
Intuitive and user-friendly interface.
Adjustable output
– Adjustable chlorine output from 0 to 100%.
– Soft-touch keypad with quick access keys.
Cell
– Self-cleaning by adjustable polarity reversal.
– High quality 10,000 hour titanium electrodes.
– Transparent cup to easily check the condition of the plates.
Technical Features DELUXE PLUS +
| 8 g/h | 12 g/h | 16 g/h | 23 g/h | 30 g/h | |
| Pool volume (m3)* | 40 | 60 | « NS 80 / LS 60″ |
« NS 120 / LS 80″ |
« NS 160 / LS 120″ |
| Normal production level (NS) | 5 g/l (can be adjusted from 2.5 g/l) | 5 g/l (can be adjusted from 2.5 g/l) | 5 g/l (can be adjusted from 2.5 g/l) | 5 g/l (can be adjusted from 2.5 g/l) | 5 g/l (can be adjusted from 2.5 g/l) |
| Minimum production level (LS) | 1,5 g/l | 1,5 g/l | 1,5 g/l | 1,5 g/l | 1,5 g/l |
| pH dosing machine | – | – | – | – | – |
| Display | LED retro iluminado |
LED retro iluminado |
LED retro iluminado |
LED retro iluminado |
LED retro iluminado |
| Boost mode | Yes (100% super chlorination up to 24 hours) |
Yes (100% super chlorination up to 24 hours) |
Yes (100% super chlorination up to 24 hours) |
Yes (100% super chlorination up to 24 hours) |
Yes (100% super chlorination up to 24 hours) |
| “LOW mode (automatic coverage)” | Yes | Yes | Yes | Yes | Yes |
| Cell type | 3P Mono | 4P Mono | 5P Mixt | 7P Mixt | 9P Mixt |
| Polarity reversal | Yes Adjustable from 2h to 16h (in 2h increments) |
Yes Adjustable from 2h to 16h (in 2h increments) |
Yes Adjustable from 2h to 16h (in 2h increments) |
Yes Adjustable from 2h to 16h (in 2h increments) |
YesAdjustable from 2h to 16h (in 2h increments) |
| Maximum pressure in the cell | 2 (bar) | 2 (bar) | 2 (bar) | 2 (bar) | 2 (bar) |
| Maximum flow in the cell (m3) | 22 ou bypass | 22 ou bypass | 22 ou bypass | 22 ou bypass | 22 ou bypass |
| Maximum water temperature | 40 ºC | 40 ºC | 40 ºC | 40 ºC | 40 ºC |
| Guarantees | ATM: 3 years | Cell: 2 years | ATM: 3 years | Cell: 2 years | ATM: 3 years | Cell: 2 years | ATM: 3 years | Cell: 2 years ele | ATM: 3 years | Cell: 2 years |
